Pillar Carving CNC Machine

Get a Price/Quote

MOQ : 1 Unit

Pillar Carving CNC Machine Specification

Product Type
Pillar Carving CNC Machine

General Use
Stone / Wood Pillar Carving

Material
Cast Iron, Steel

Type
CNC Router

Capacity
One pillar per cycle

Weight (kg)
1850 kg

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Bar Feeder
Yes

Power Source
Electric

Power Consumption
3.2 kW

Rigidity
High

Voltage
380V / 50Hz

Motor
Servo Motor

Table Size
1800 x 400 mm

Spindle Speed
24000 RPM

Axial Choice
3 Axis

Dimension (L*W*H)
2500 x 1600 x 2100 mm

Feature
High Precision, Automated Operation

Color
Blue & White

Cooling System
Water Cooling

Supported File Formats
DXF, G-code

Drive System
Ball Screw and Linear Guideway

Max Workpiece Diameter
400 mm

Control Interface
LCD Touch Panel

Positioning Accuracy
0.05 mm

Dust Collection
Integrated

Operating Temperature
5C - 40C

Lubrication System
Automatic

Repeatability
0.02 mm

Spindle Power
5.5 kW

Max Workpiece Length
1800 mm

Noise Level
<75 dB

Pillar Carving CNC Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

Pillar Carving CNC Machine About

Experience the exclusive Pillar Carving CNC Machine-your top-ranking solution for automated, high-precision pillar carving on stone and wood. Built with a high-rigidity cast iron frame and crackerjack 5.5 kW spindle, this champion delivers elite accuracy with 0.05 mm positioning and 0.02 mm repeatability. With an automatic lubrication system, water cooling, LCD touch control, and integrated dust collection, operation is seamless and efficient. Get it now under our special promotion and take your manufacturing process to a professional, unmatched level-trusted by manufacturers, suppliers, and traders across India.

Applications & Surface of Use: Achieve Versatility

Maximize your craftsmanship with the Pillar Carving CNC Machine, ideal for surfaces like stone and wood pillars, columns, or balusters. Beyond traditional applications, this machine also excels in custom engravings, decorative art, and signage. To start, simply load your DXF or G-code file through the LCD touch panel. Secure the workpiece using the integrated bar feeder and begin automated fabrication-perfect for workshops aiming for high-quality, repeatable designs every cycle.

Packaging, Supply & Domestic Offerings: Seamless Service

Our Pillar Carving CNC Machine is packed with utmost care, ensuring secure transport services to your preferred destination. We offer reliable, timely dispatch to minimize your expenditure without compromising product safety. With a robust supply ability, we serve the main domestic market efficiently, catering to manufacturers, suppliers, and traders across India. Take advantage of our current offer and enjoy a hassle-free purchase process with continued customer support.

FAQ's of Pillar Carving CNC Machine:

Q: How do I operate the Pillar Carving CNC Machine?

A: Operation is user-friendly with the LCD touch panel interface. Load your design file (DXF or G-code), set the parameters, secure the workpiece using the bar feeder, and initiate the automated carving process.

Q: What materials is this CNC machine suitable for?

A: This machine is designed to precisely carve both stone and wood pillars, and can also be used for customized engravings, decorative columns, and similar applications.

Q: Where can I use the Pillar Carving CNC Machine?

A: It's suitable for workshops, manufacturing facilities, and artisan studios focused on architectural elements, furniture production, or artistic installations.

Q: What benefits does the integrated dust collection and lubrication system provide?

A: The integrated dust collection keeps your workspace cleaner, while the automatic lubrication system ensures smooth operation, reduces maintenance, and extends the machine's lifespan.

Q: When can I expect the machine to be delivered after placing an order?

A: With our efficient transport services and ample supply, delivery times are minimized-details and timelines will be confirmed at the time of order based on your location.
