Single Head Heavy-Duty Stone Engraving CNC

Send Inquiry

Request To Call Back

Single Head Heavy-Duty Stone Engraving CNC

Get a Price/Quote

MOQ : 1 Unit

Single Head Heavy-Duty Stone Engraving CNC Specification

Product Type
Single Head Heavy-Duty Stone Engraving CNC

General Use
Stone Engraving/Carving

Material
Granite, Marble, Stone

Type
CNC Router for Stone

Capacity
Customized as per Requirement

Weight (kg)
2200 kg

Computerized
Yes

Automatic
Fully Automatic

PLC Control
Yes

Power Source
Electric

Power Consumption
4.5 kW

Rigidity
High

Voltage
380V/50Hz

Motor
Servo Motor

Table Size
1800 mm x 2500 mm

Spindle Speed
0-24000 RPM

Axial Choice
XYZ (3 Axis)

Dimension (L*W*H)
3200 mm x 2200 mm x 2000 mm

Feature
Heavy Duty, High Precision Engraving

Color
Blue & White

Cooling System
Water Cooling

Transmission System
Rack and Pinion (X, Y-axis), Ball Screw (Z-axis)

Maximum Engraving Depth
300 mm

Drive System
Ball Screw & Linear Guideway

Lubrication System
Automatic

Software Compatibility
Compatible with ArtCAM, Type3, JD Paint

Working Mode
Step Motor or Servo Motor

Max Traveling Speed
25000 mm/min

Control System
DSP Control / NC Studio

Repeat Positioning Accuracy
0.03 mm

Table Structure
Heavy Cast Iron Body

Spindle Power
5.5 kW Water-Cooled

Dust Collection System
Optional

Applicable Stone Thickness
Up to 300 mm

Operating Temperature
5C - 40C

Max Working Speed
15000 mm/min

Single Head Heavy-Duty Stone Engraving CNC Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Single Head Heavy-Duty Stone Engraving CNC

Experience commanding performance and marvelous precision with the Single Head Heavy-Duty Stone Engraving CNC. Engineered for cost-effective operation, this sophisticated machine delivers rare savings through high-speed engraving and minimized manual oversight. Boasting a brilliant 5.5 kW water-cooled spindle, it engraves up to 300 mm deep with an astounding repeat positioning accuracy of 0.03 mm. Supported by a high-rigidity cast iron body, advanced ball screw and linear guideways, and compatibility with leading software, this CNC is ideal for discerning manufacturers, suppliers, and traders seeking reliable, high-precision results in stonework.

Applications and Usage of Single Head Heavy-Duty Stone Engraving CNC

This brilliant CNC router is custom-designed for demanding stone carving and engraving tasks. Employing a fully automatic, PLC-controlled system, it is perfectly suited for granite, marble, and other stones up to 300 mm thickness. Common uses include monument crafting, architectural elements, artistic reliefs, and custom signage. Its cost-effective performance makes it valuable for manufacturers, architects, and artisans who require both high productivity and consistent accuracy, ensuring rare, professional-grade results in every project.

Export Markets, Certifications & Delivery Process

Our Single Head Heavy-Duty Stone Engraving CNC is a sought-after export for international markets, especially across Asia, Europe, and the Middle East. Orders are handled with meticulous order processing, robust packing & timely dispatch. Transportation is coordinated for safe delivery within agreed timelines. The machine comes certified for industrial standards, ensuring buyers receive advanced technology with every shipment. Globally trusted, our CNC is your partner in cost-effective, large-scale stone engraving projects.

FAQ's of Single Head Heavy-Duty Stone Engraving CNC:

Q: How does the Single Head Heavy-Duty Stone Engraving CNC ensure high precision in engraving?

A: The CNC achieves exceptional accuracy using a ball screw drive system, linear guideways, and repeat positioning accuracy of 0.03 mm, ensuring each engraving is consistently brilliant and precise.

Q: What types of stone materials can be engraved with this machine?

A: This heavy-duty CNC is suitable for a wide range of stone materials, including granite, marble, and other hard stones, supporting up to 300 mm in thickness.

Q: When can I expect delivery after placing my order?

A: Delivery times depend on your location and order specifics. However, once order processing, robust packing, and dispatch are complete, we coordinate transportation for safe and timely delivery.

Q: Where is this CNC router typically used?

A: It is ideal for use in manufacturing facilities, architectural workshops, monument crafting units, and by artisans involved in custom stonework or sign making.

Q: What are the benefits of the machine's water-cooled spindle?

A: The water-cooled 5.5 kW spindle provides effective cooling during intensive use, enhancing spindle life, maintaining consistent performance, and contributing to long-term cost savings.

Q: How does the dust collection system improve usage?

A: An optional dust collection system efficiently removes stone particles, ensuring a clean working environment, reducing maintenance downtime, and prolonging the machine's operating lifespan.
